Tandberg 1200X/1241X, 4 Track, Reel-to-Reel Tape Recorder
Tandberg 1200X/1241X, 4 Track, Reel-to-Reel Tape Recorder
Call us on 03 9882 0372 for more information or simply checkout online. Items covered under the HiFi Disposals warranty are serviced and guaranteed by Tivoli Hi-Fi.
Regular price
$500.00 AUD
Regular price
Sale price
$500.00 AUD
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
Tandberg 1241X, 4 Track, Reel-to-Reel Tape Recorder
Key Features and Specifications
Transistorised Design: It marked a major evolution as Tandberg's fully transistorised machine in this line, replacing older vacuum-tube indicators with conventional mechanical level meters. [1]
Cross-Field Biasing: It features a three-head arrangement utilising Tandberg's distinct cross-field biasing technique, which improved high-frequency response and signal-to-noise ratios at slower tape speeds. [1]
Configurations: Available in both half-track (2-track) and quarter-track (4-track) stereo versions. [1, 2]
Controls: Offers independent record and playback volume adjustments, standard treble and bass controls, and a dedicated input selector for line, pickup, or mixed inputs. [1, 2]
You can learn more about its history and design background on the Reel-to-Reel Tape Recorder Directory. Discussions on how its circuitry compares to older models can also be found on the Vintage Radio Forum. [1, 2]
Specifications
Track system: 2/4-track, 2-channel, stereo/monaural system
Heads: 1 x erase, 1 x record/playback, 1 x crossfield
Reel size: up to 7 inch reel
Tape speeds: 1 7⁄8 3 3⁄4 7 1⁄2 ips
Wow and flutter: 0.1% (7 1⁄2 ips)
Frequency response: 30Hz to 20kHz (7 1⁄2 ips)
Signal to Noise Ratio: 58dB
Output: 0.75V (line)
Output power: 10 watts
Semiconductors: 36 x transistors, 1 x zener diode, 2 x diodes, 1 x bridge rectifier
Dimensions: 15-3/8 x 11-1/2 x 6-7/8 inches
Weight: 23.4lbs
Includes original case and Circuit Diagram
